ADI低相位噪聲放大器
發布時間：2022-02-25 17:19:24 瀏覽：835
ADI低相位噪聲放大器相對于大多數需要高信號完整性的技術應用非常重要。尤其是在儀表儀器、國防科技和電信應用領域。隨著振蕩器的不斷完善，ADI低相位噪聲放大器在這些技術應用中顯得越來越重要。相位噪聲被描述為近載波噪聲，通常表現為時鐘信號中的抖動。ADI提供多種多樣的低相位噪聲放大器組合，以滿足Lo網絡、接收器和發射機的各種規定要求。ADI的產品組合支持各種功率級別和頻率，以提供適合特定技術應用的解決方案。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.bgbga.com/brand/25.html
產品型號 | # of Channels | Freq Response RF (min) | Freq Response RF (max) | Gain dB (typ) | Residual Phase Noise (typ) | OIP3 (typ) | Vs+ (min) | Vs+ (max) | Is (typ) |
|
| Hz | Hz | dB | dBc/Hz | dBm | V | V | A |
ADL8150-Die | 1 | 6G | 14G | 13 | -172 | 31.5 | 3 | 6 | 76m |
ADL8150ACPZN | 1 | 6G | 14G | 12 | -172 | 30 | 3 | 6 | 74m |
ADPA9002 | 1 | 0 | 10G | 15.5 |
| 40.5 | 10 | 15 | 385m |
HMC8411 |
| 10M | 10G | 15 |
| 34 |
|
| 55m |
HMC8411-EP |
| 10M | 10G | 15 |
| 34 |
|
| 55m |
HMC8412-Die | 1 | 400M | 10G | 15 |
| 32 | 3 | 6 | 60m |
HMC8412LP2FE | 1 | 400M | 11G | 15 |
| 33 |
| 6 | 60m |
HMC998A-Die | 1 | 0 | 22G | 14.5 |
| 43 | 11 | 15 | 500m |
HMC998ALP5E | 1 | 0.1G | 20G | 11 |
| 41 | 11 | 15 | 500m |
HMC998APM5E | 1 | 0 | 22G | 15 |
| 42 | 11 | 15 | 500m |
HMC907A-Die | 1 | 200M | 22G | 13.5 |
| 41 | 8 | 11 | 350m |
HMC907ALP5E | 1 | 200M | 22G | 13 |
| 40 | 8 | 11 | 350m |
HMC907APM5E | 1 | 200M | 22G | 13 |
| 40 | 8 | 11 | 350m |
HMC797A-Die | 1 | 0 | 22G | 15 | -161 | 41 | 8 | 11 | 400m |
HMC797ALP5E | 1 | 0 | 22G | 15 | -161 | 41 | 8 | 11 | 400m |
HMC797APM5E | 1 | 0 | 22G | 15 | -161 | 41 | 8 | 11 | 400m |
HMC5805A | 1 | 0 | 40G | 11.5 |
| 29 | 10 | 12 | 175m |
HMC589A | 1 | 0 | 4G | 21 | -172 | 32 |
|
| 82m |
HMC930A-Die | 1 | 0 | 40G | 13 |
| 33.5 |
|
| 175m |
HMC788A | 1 | 10M | 10G | 14 | -153 | 33 | 4.5 | 5.5 | 76m |
ADL5611 | 1 | 30M | 6G | 22.2 | -156 | 40 | 4.75 | 5.25 | 91m |
ADL5544 | 1 | 30M | 6G | 17.4 | -156 | 34.9 | 4.75 | 5.25 | 55m |
ADL5602 | 1 | 50M | 4G | 19.3 | -162 | 42 | 4.5 | 5.5 | 89m |
ADL5521 | 1 | 400M | 4G | 20.8 |
| 37 | 3 | 5 | 60m |
HMC606-Die | 1 | 2G | 18G | 12.5 | -166 | 22 |
|
| 64m |
HMC606LC5 | 1 | 2G | 18G | 12.5 | -166 | 22 |
|
| 64m |
HMC3653 | 1 | 7G | 15G | 15 | -160 | 28 |
| 6 | 44m |
HMC460-Die | 1 | 0G | 20G | 14 | -155 | 28 |
|
| 75m |
HMC460LC5 | 1 | 0 | 20G | 14 | -155 | 29 |
| 8 | 75m |
HMC519-Die | 1 | 18G | 32G | 15 | -150 | 26 |
|
| 75m |
HMC519LC4 | 1 | 18G | 31G | 14.4 | -150 | 23 |
| 3 | 75m |
HMC311LP3 | 1 | 0M | 6G | 14.5 | -165 | 32 | 4.5 | 5.5 | 55m |
HMC311SC70 | 1 | 0M | 8G | 15 | -165 | 30 | 4.5 | 5.5 | 55m |
HMC311ST89 | 1 | 0M | 6G | 15 | -165 | 27 | 4.5 | 5.5 | 55m |
HMC326 | 1 | 3G | 4.5G | 21 | -167 | 36 |
| 5 | 130m |
