產(chǎn)品詳情介紹
| Part # | Attenuator Type | Frequency Range (GHz) | Insertion Loss (dB) | Attenuation Range (dB) | Flatness (±dB) | VSWR Max. | |
| Min | Max | ||||||
| CVA34-50 | Dial | 0.406 | 0.4061 | 0.5 | 50 | N/A | 1.50:1 |
| CA820-50 | Standard | 10.7 | 12.7 | 0.5 | 50 | 1.9 | 1.50:1 |
| CA821-50 | Standard | 10.7 | 14.5 | 0.5 | 50 | 2.25 | 1.50:1 |
| CA820-50/D | Dial | 10.7 | 12.7 | 0.5 | 50 | 1.9 | 1.50:1 |
| CA821-50/D | Dial | 10.7 | 14.5 | 0.5 | 50 | 2.25 | 1.50:1 |
| CA820-50/DK | Knob | 10.7 | 12.7 | 0.5 | 50 | 1.9 | 1.50:1 |
| CA821-50/DK | Knob | 10.7 | 14.5 | 0.5 | 50 | 2.25 | 1.50:1 |
| CA824-50 | Standard | 13 | 14.5 | 0.5 | 50 | 1 | 1.50:1 |
| CA824-50/D | Dial | 13 | 14.5 | 0.5 | 50 | 1 | 1.50:1 |
| CA824-50/DK | Knob | 13 | 14.5 | 0.5 | 50 | 1 | 1.50:1 |
| CA823-50 | Standard | 5.8 | 6.5 | 0.5 | 50 | 2 | 1.50:1 |
| CA823-50/D | Dial | 5.8 | 6.5 | 0.5 | 50 | 2 | 1.50:1 |
| CA823-50/DK | Knob | 5.8 | 6.5 | 0.5 | 50 | 2 | 1.50:1 |
| CVA9-60 | Standard | 6 | 11 | 0.5 | 60 | N/A | 1.50:1 |
| CVA23-60 | Standard | 6 | 18 | 0.9 | 60 | N/A | 1.50:1 |
| CVA23-60/NF | Standard | 6 | 18 | 0.5 | 60 | N/A | 1.50:1 |
| CVA9-60/D | Dial | 6 | 11 | 0.5 | 60 | N/A | 1.50:1 |
| CVA23-60/DNF | Dial | 6 | 18 | 0.5 | 60 | N/A | 1.50:1 |
| CVA23-60/D | Dial | 6 | 18 | 0.9 | 60 | N/A | 1.50:1 |
| CVA809-60 | Standard | 6 | 11 | 0.5 | 60 | N/A | 1.50:1 |
| CVA823-60 | Standard | 6 | 18 | 0.5 | 60 | N/A | 1.50:1 |
| CVA809-60/D | Dial | 6 | 11 | 0.5 | 60 | N/A | 1.50:1 |
| CVA823-60/D | Dial | 6 | 18 | 0.5 | 60 | N/A | 1.50:1 |
| CVA809-60/DK | Knob | 6 | 11 | 0.5 | 60 | N/A | 1.50:1 |
| CVA823-60/DK | Knob | 6 | 18 | 0.5 | 60 | N/A | 1.50:1 |
| CA805-50 | Standard | 7.2 | 7.8 | 0.5 | 50 | 1.25 | 1.50:1 |
| CA807-50 | Standard | 7.2 | 8.4 | 0.5 | 50 | 2 | 1.50:1 |
| CA805-50/D | Dial | 7.2 | 7.8 | 0.5 | 50 | 1.25 | 1.50:1 |
| CA807-50/D | Dial | 7.2 | 8.4 | 0.5 | 50 | 2 | 1.50:1 |
| CA805-50/DK | Knob | 7.2 | 7.8 | 0.5 | 50 | 1.25 | 1.50:1 |
| CA807-50/DK | Knob | 7.2 | 8.4 | 0.5 | 50 | 2 | 1.50:1 |
| CVA11-60 | Standard | 7.9 | 12.7 | 0.5 | 60 | N/A | 1.50:1 |
| CVA11-60/D | Dial | 7.9 | 12.7 | 0.5 | 60 | N/A | 1.50:1 |
| CA809-50 | Standard | 7.9 | 8.4 | 0.5 | 50 | 1.25 | 1.50:1 |
| CA809-50/D | Dial | 7.9 | 8.4 | 0.5 | 50 | 1.25 | 1.50:1 |
| CA809-50/DK | Knob | 7.9 | 8.4 | 0.5 | 50 | 1.25 | 1.50:1 |
| CVA26-050/DD | Dial | DC | 2.5 | 1 | 50 | N/A | 1.50:1 |
