產品詳情介紹
| Part Number | Input Voltage | Output Voltage | Vo trim range | Output Current | Output Power | Efficiency | Isolation Voltage | without heat spreader Size (LxWxH) |
| Q48SC12025 | 36~75V | 12V | 8~13.2V | 25A | 300W | 95.1% | 1500V | 57.9 x 36.8 x 11.2 mm |
| Q48SC12033 | 36~75V | 12V | 8~13.2V | 33A | 400W | 95.0% | 1500V | 57.9 x 36.8 x 11.2 mm |
| Q48SC12042 | 36~75V | 12V | 8~13.2V | 42A | 500W | 95.0% | 1500V | 57.9 x 36.8 x 12.7 mm |
| Q48SC12050 | 36~75V | 12V | 8~13.2V | 50A | 600W | 94.2% | 1500V | 58.4 x 36.8 x 12.7 mm |
