28AV500微型高壓電源模塊DC-DC
發布時間：2023-10-17 16:50:13 瀏覽：901
美國PICO的高壓DC-DC電源模塊系列產品，提供多樣化的高壓電源模塊，產品體積小至12.7mm*12.7mm長寬，重量不到4g，輸出電壓高達10KV,
PICO高壓DC-DC電源模塊產品，符合美軍標MIL-STD-883標準，工作溫度支持-55°C至+85°C，而不需要散熱器。
插件型號 | 貼片型號 | Input | Output | Max. | Max. | Eff. @ | Input | * | ** |
Volt. | Volt. | Load | Output | Full | Current | Output | Full |
(V DC) | (V DC) | Current | Power | Load | Full | Volt. | Load |
|
| (mA) | (watts) | Typical | Load | Ripple | Output |
|
|
|
| (%) | Typical | @ Full | Volt. |
|
|
|
|
| (mA) | Load | Tolerance |
|
|
|
|
|
| (Vp-p max) | (± %) |
|
|
|
|
|
|
|
|
5AV100 | 5SMV100 | 5 | 100 | 12.5 | 1.25 | 78 | 321 | 0.9 | 3 |
5AV150 | 5SMV150 | 5 | 150 | 8.3 | 1.25 | 76 | 329 | 0.9 | 3 |
5AV200 | 5SMV200 | 5 | 200 | 6.25 | 1.25 | 75 | 333 | 0.9 | 3 |
5AV250 | 5SMV250 | 5 | 250 | 5 | 1.25 | 75 | 333 | 0.9 | 3 |
5AV300 | 5SMV300 | 5 | 300 | 4.16 | 1.25 | 70 | 357 | 1.2 | 3 |
5AV350 | 5SMV350 | 5 | 350 | 3.57 | 1.25 | 70 | 357 | 1.2 | 3 |
5AV400 | 5SMV400 | 5 | 400 | 3.12 | 1.25 | 70 | 357 | 1.2 | 3 |
5AV450 | 5SMV450 | 5 | 450 | 2.77 | 1.25 | 70 | 357 | 1.5 | 3 |
5AV500 | 5SMV500 | 5 | 500 | 2.5 | 1.25 | 70 | 357 | 1.5 | 3 |
12AV100 | 12SMV100 | 12 | 100 | 12.5 | 1.25 | 80 | 130 | 0.9 | 3 |
12AV150 | 12SMV150 | 12 | 150 | 8.3 | 1.25 | 79 | 132 | 0.9 | 3 |
12AV200 | 12SMV200 | 12 | 200 | 6.25 | 1.25 | 78 | 134 | 0.9 | 3 |
12AV250 | 12SMV250 | 12 | 250 | 5 | 1.25 | 75 | 139 | 0.9 | 3 |
12AV300 | 12SMV300 | 12 | 300 | 4.16 | 1.25 | 75 | 139 | 1.2 | 3 |
12AV350 | 12SMV350 | 12 | 350 | 3.57 | 1.25 | 75 | 139 | 1.2 | 3 |
12AV400 | 12SMV400 | 12 | 400 | 3.12 | 1.25 | 75 | 139 | 1.2 | 3 |
12AV450 | 12SMV450 | 12 | 450 | 2.77 | 1.25 | 75 | 139 | 1.5 | 3 |
12AV500 | 12SMV500 | 12 | 500 | 2.5 | 1.25 | 75 | 139 | 1.5 | 3 |
15AV100 | 15SMV100 | 15 | 100 | 12.5 | 1.25 | 80 | 104 | 0.9 | 3 |
15AV150 | 15SMV150 | 15 | 150 | 8.3 | 1.25 | 79 | 105 | 0.9 | 3 |
15AV200 | 15SMV200 | 15 | 200 | 6.25 | 1.25 | 78 | 107 | 0.9 | 3 |
15AV250 | 15SMV250 | 15 | 250 | 5 | 1.25 | 75 | 111 | 0.9 | 3 |
15AV300 | 15SMV300 | 15 | 300 | 4.16 | 1.25 | 75 | 111 | 1.2 | 3 |
15AV350 | 15SMV350 | 15 | 350 | 3.57 | 1.25 | 75 | 111 | 1.2 | 3 |
15AV400 | 15SMV400 | 15 | 400 | 3.12 | 1.25 | 75 | 111 | 1.2 | 3 |
15AV450 | 15SMV450 | 15 | 450 | 2.77 | 1.25 | 75 | 111 | 1.5 | 3 |
15AV500 | 15SMV500 | 15 | 500 | 2.5 | 1.25 | 75 | 111 | 1.5 | 3 |
24AV100 | 24SMV100 | 24 | 100 | 12.5 | 1.25 | 76 | 69 | 0.9 | 3 |
24AV150 | 24SMV150 | 24 | 150 | 8.3 | 1.25 | 73 | 71 | 0.9 | 3 |
24AV200 | 24SMV200 | 24 | 200 | 6.25 | 1.25 | 73 | 71 | 0.9 | 3 |
24AV250 | 24SMV250 | 24 | 250 | 5 | 1.25 | 70 | 74 | 0.9 | 3 |
24AV300 | 24SMV300 | 24 | 300 | 4.16 | 1.25 | 73 | 71 | 1.2 | 3 |
24AV350 | 24SMV350 | 24 | 350 | 3.57 | 1.25 | 73 | 71 | 1.2 | 3 |
24AV400 | 24SMV400 | 24 | 400 | 3.12 | 1.25 | 73 | 71 | 1.2 | 3 |
24AV450 | 24SMV450 | 24 | 450 | 2.77 | 1.25 | 73 | 71 | 1.5 | 3 |
24AV500 | 24SMV500 | 24 | 500 | 2.5 | 1.25 | 73 | 71 | 1.5 | 3 |
28AV100 | 28SMV100 | 28 | 100 | 12.5 | 1.25 | 75 | 60 | 0.9 | 3 |
28AV150 | 28SMV150 | 28 | 150 | 8.3 | 1.25 | 76 | 59 | 0.9 | 3 |
28AV200 | 28SMV200 | 28 | 200 | 6.25 | 1.25 | 75 | 60 | 0.9 | 3 |
28AV250 | 28SMV250 | 28 | 250 | 5 | 1.25 | 70 | 64 | 0.9 | 3 |
28AV300 | 28SMV300 | 28 | 300 | 4.16 | 1.25 | 73 | 61 | 1.2 | 3 |
28AV350 | 28SMV350 | 28 | 350 | 3.57 | 1.25 | 73 | 61 | 1.2 | 3 |
28AV400 | 28SMV400 | 28 | 400 | 3.12 | 1.25 | 73 | 61 | 1.2 | 3 |
28AV450 | 28SMV450 | 28 | 450 | 2.77 | 1.25 | 73 | 61 | 1.5 | 3 |
PICO的電源模塊產品，應用于航空航天、軍事、儀表等項目，其產品品質獲得眾多高可靠性要求認可。
深圳市立維創展科技是PICO公司的分銷商。提供進口PICO電源模塊、軍用電源模塊、高壓電源模塊、小型變壓器、MIL-PRF-21038/27規格變壓器、脈沖變壓器、400 MHz電力變壓器、MIL-STD-1553接口變壓器、音頻變壓器、功率電感、微型功率電感、EMI電感、薄DC-直流電源模塊、軍用DC-DC電源模塊、磚塊DC-DC電源模塊、高壓DC-DC、AC-DC電源模塊、開關直流電源模塊、隔離電源模塊、航空電源模塊等功能電源模塊和功率轉換器。原裝產品進口，質量保證，歡迎咨詢。
