?ADI單輸出壓控振蕩器(VCO)
發布時間：2022-12-02 17:04:15 瀏覽：643
ADI壓控振蕩器(VCO)鎖相振蕩器(PLO)產品線適用多種應用。ADI多樣化的產品線包含多種機器設備，選用單芯片構造，在環境溫度、沖擊和工藝參數下具備優異的相位噪聲性能指標。ADI為滿足多元化設計的需求，還提供了超小型、低相位噪聲、低功耗、寬調諧范圍選擇。
應用：
?點到點及點到多點無線通信
?檢測設備和工業控制系統
?SATCOM
?醫療器械
?軍用雷達、EW和ECM
?VSAT
?無線網絡基礎設施
ADI公司為鋰離子電池、鉛酸電池、鎳基電池等所有可充電電池化學應用制造出深厚的性能卓越脈沖電池充電器。LINEAR脈沖充電器無需微控制器/MOSFET/堵塞二極管，提供開關充電器等諸多優勢，簡單性和線性充電器相似。
深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。
詳情了解LINEAR電源模塊請點擊：http://www.bgbga.com/brand/19.html
產品型號 | Freq Response RF (max) | Freq Response RF (min) | Phase Noise @ 10k | Phase Noise @ 100k | Output Power (typ) | Vtune (min) | Vtune (max) | Vs (typ) | Is (typ) |
| Hz | Hz | dBc/Hz | dBc/Hz |
| V | V | V | A |
HMC6380 | 16G | 8G | -64 | -92 | 6 dBm | 0 | 23 | 5 | 75m |
HMC732 | 12G | 6G | -65 | -95 | 1 dBm | 0 | 23 | 5 | 57m |
HMC733 | 20G | 10G | -60 | -90 | 2 dBm | -0.25 | 23 | 5 | 70m |
HMC532 | 7.9G | 7.1G | -80 | -101 | 14 dBm | 1 | 13 | 3 | 85m |
HMC586 | 8G | 4G | -75 | -100 | 5 dBm | 0 | 18 | 5 | 55m |
HMC587 | 10G | 5G | -65 | -95 | 5 dBm | 0 | 18 | 5 | 55m |
HMC505 | 7.4G | 6.8G | -80 | -106 | 11 dBm | 1 | 11 | 3 | 80m |
HMC506 | 8.7G | 7.8G | -80 | -103 | 14 dBm | 1 | 11 | 3 | 77m |
HMC385 | 2.5G | 2.25G | -89 | -115 | 4.5 dBm | 0 | 10 | 3 | 35m |
HMC386 | 2.8G | 2.6G | -88 | -115 | 5 dBm | 0 | 10 | 3 | 35m |
HMC388 | 3.4G | 3.15G | -88 | -113 | 4.9 dBm | 0 | 10 | 3 | 39m |
HMC389 | 3.55G | 3.35G | -89 | -112 | 4.7 dBm | 0 | 10 | 3 | 41m |
HMC390 | 3.9G | 3.55G | -87 | -112 | 4.7 dBm | 0 | 10 | 3 | 42m |
HMC391 | 4.45G | 3.9G | -81 | -106 | 5 dBm | 0 | 10 | 3 | 30m |
HMC416 | 3G | 2.75G | -89 | -114 | 4.5 dBm | 0 | 10 | 3 | 37m |
HMC429 | 5G | 4.45G | -79 | -105 | 4 dBm | 0 | 10 | 3 | 30m |
HMC466 | 6.72G | 6.1G | -73 | -101 | 4.5 dBm | 0 | 10 | 3 | 13m |
HMC358 | 6.8G | 5.8G | -82 | -110 | 11 dBm | 0 | 10 | 3 | 100m |
HMC384 | 2.25G | 2.05G | -89 | -112 | 3.5 dBm | 0 | 10 | 3 | 35m |
HMC430 | 5.5G | 5G | -80 | -103 | 2 dBm | 0 | 10 | 3 | 27m |
HMC431 | 6.1G | 5.5G | -80 | -102 | 2 dBm | 0 | 10 | 3 | 27m |
HMC6475 | 7.5G | 3.9G | -79 | -106 | 5 dBm | 0 | 23 | 0 | 53m |
