EC7BW18

20W

8.5~160V

12V, 15V, 5V, ±12V, ±15V, ±24V

3KVac Isolation
UL62368-1
EN45545-2
EN50155 Compliant

2.00x1.00x0.40(DIP)

EC3AW

3W

18~72V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V

500/1.5K/3KVdc Isolation

1.25x0.80x0.40(DIP24)
1.25×0.80x0.45(SMD24)

EC4AW

6W

18~72V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V

1.5K/3KVdc Isolation

1.25x0.80x0.40(DIP24)
1.25×0.80x0.45(SMD24)

EC6AW

8W

18~75V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V

1.5KVdc Isolation
EN50155 Compliant

1.25x0.80x0.40(DIP24)
1.25×0.80x0.45(SMD24)

EC2SBW

10W

18~75V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V

1.5KVdc Isolation

1.00x1.00x0.40(DIP)

EC4BW

10W

18~72V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V

500Vdc Isolation
EN55022 Class A

2.00x1.00x0.40(DIP)

EC7AW

10W

18~74V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V

3KVdc Isolation
EN55032 Class A

1.25x0.80x0.40(DIP24)

EC6AW-110

10W

43~160V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V

3KVdc Isolation
UL60950-1 & CB
EN45545-2
EN50155 Compliant

1.25x0.80x0.50(DIP24)

EC8AW

15W

18~75V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V

1.5KVdc Isolation
EN55032 Class A

1.25x0.80x0.40(DIP24)

EC3SBW

15W

18~75V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V

1.5KVdc Isolation

1.00x1.00x0.40(DIP)

EC5BW

15W

18~75V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V

1.5KVdc Isolation
EN55032 Class A

2.00x1.00x0.40(DIP)

EC5C

15W

18~72V, 9~36V

12V, 15V, 3.3V, 5/±12V, 5/±15V, 5V, ±12V, ±15V, ±5V

500Vdc Isolation
EN60950-1

2.00x2.00x0.40(DIP)

EC1SC

20W

18~72V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V

EN55022 Class A

2.00×1.60×0.45(DIP)

EC4SBW

20W

18~75V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V

1.5KVdc Isolation

1.00x1.00x0.40(DIP)

EC7BW-110

20W

43~160V

5V, 12V, 15V, ±12V, ±15V

3KVdc Isolation
UL60950-1
EN45545-2
EN50155 Compliant

2.00x1.00x0.40(DIP)

EC7BW

20W

9~36V, 18~75V

3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V

1.5KVdc Isolation
EN45545-2
EN50155 Compliant

2.00x1.00x0.40(DIP)

EC3SCW

30W

18~75V, 9~36V

12V, 15V, 3.3V, 5V

1.5KVdc Isolation
EN60950-1

2.00×1.60×0.40(DIP)

EC5SBW

30W

18~75V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V

1.5KVdc Isolation
UL62368-1

1.00x1.00x0.40(DIP)

EC9BW

30W

18~75V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V

1.5KVdc Isolation

2.00x1.00x0.40(DIP)

ECLB40W

40W

18~75V, 9~36V

12V, 15V, 3.3V, 5V, ±12V, ±15V

1.5KVdc Isolation
With Mounting Inserts

2.05x1.20x0.40(DIP)

ECLB40W-110

40W

43~160V

12V, 15V, 3.3V, 5V, ±12V, ±15V, ±24V

3KVdc Isolation
UL60950-1
EN45545-2
EN50155 Compliant

2.05x1.20x0.40(DIP)

ECLB60W

60W

18~75V, 9~36V

3.3V, 5V, 12V, 15V, ±12V, ±15V

1.5KVdc Isolation
With Mounting Inserts

2.05x1.20x0.40(DIP)

ECLB75W

75W

18~75V, 9~36V

5V, 12V, 15V, ±12V, ±15V, ±24V

2.25KVdc Isolation
With Mounting Inserts

2.05x1.20x0.40(DIP)
