ADI全差分放大器
發布時間：2021-06-18 17:03:19 瀏覽：6937
ADI全差分放大器具備高精度的直流特性，根據其差分I/O結構特征能夠更好的控制高頻率PSRR和CMRR。差分輸入和差分輸出還能夠根據減少ADC傳輸?shù)降目傊C波失真來優化操作系統，ADI差分放大器能夠?qū)味溯斎胩幚沓苫パa(bǔ)式差分輸出，或者將差分輸入處理成差分輸出。這些放大器諧波失真低，能夠驅動精密高速模數轉換器（ADC）。
ADI的全差分放大器配置了VOCM引腳的精密高速差分放大器，為與模數轉換器（ADC）的銜接提供了核心而快捷的處理方案。這為銜接ADC提供了一個方便的處理方案。差分輸出提供了傳統放大器兩倍的輸出信號，能夠在低壓電源模塊上獲取最大的輸出信號。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.bgbga.com/brand/25.html
或聯系ADI的銷售工程師： 0755-83050846 QQ ：3312069749
產品型號 | # of Channels | BW -3 dB (typ) | Slew Rate (typ) | Gain dB (min) | Gain dB (max) | Is (typ) | Vs span (min) | Vs span (max) |
|
| Hz | V/us | dB | dB | A | V | V |
ADL5580 | 1 | 10G | 24k | 10 | 10 | 276m | 4.5 | 5.5 |
ADA4945-1 | 1 | 200M | 600 |
|
| 4m | 2.7 | 11 |
ADL5569 | 2 | 6.5G | 24k | 6 | 20 | 86m | 4.75 | 5.25 |
LTC6432A-15 | 1 | 1.4G |
| 15.2 | 15.2 | 166m | 4.75 | 5.25 |
LTC6432B-15 | 1 | 1.4G |
| 15.2 | 15.2 | 166m | 4.75 | 5.25 |
LTC6419 | 2 | 1.4G | 3.3k | 0 |
| 52m | 2.7 | 5.25 |
ADL5567 | 2 | 4.3G | 20000 | 0 | 20 | 138m | 3.15 | 5.25 |
ADL5205 | 2 | 1.2G | 5000 | -9 | 26 | 175m | 3.15 | 5.25 |
LTC6363 | 1 | 35M | 75 | -20 |
| 1.7m | 2.8 | 11 |
LTC6363-0.5 | 1 | 60M | 75 | -6 | -6 | 1.7m | 2.8 | 11 |
LTC6363-1 | 1 | 35M | 75 | 0 | 0 | 1.7m | 2.8 | 11 |
LTC6363-2 | 1 | 21M | 75 | 6 | 6 | 1.7m | 2.8 | 11 |
ADA4961 | 1 | 3.2G | 12k | -6 | 15 | 150m | 3.3 | 5.5 |
LTC6430A-20 | 1 | 2G |
| 20.8 | 20.8 | 170m | 4.75 | 5.25 |
LTC6430B-20 | 1 | 2G |
| 20.8 | 20.8 | 170m | 4.75 | 5.25 |
LTC6430A-15 | 1 | 2G |
| 15.2 | 15.2 | 160m | 4.75 | 5.25 |
LTC6430B-15 | 1 | 2G |
| 15.2 | 15.2 | 160m | 4.75 | 5.25 |
ADL5566 | 2 | 4.5G | 20k | 3 | 16 | 160m | 2.8 | 5.2 |
LTC6417 | 1 | 1.6G | 10k | 0 | 0 | 123m | 4.75 | 5.25 |
LTC6362 | 1 | 34M | 45 | 0 | 0 | 900μ | 2.8 | 5.25 |
AD8476 | 1 | 6M | 10 | 1 | 1 | 330μ | 3 | 18 |
ADA4940-1 | 1 | 260M | 95 |
|
| 1.25m | 3 | 7 |
ADA4940-2 | 2 | 260M | 95 |
|
| 1.25m | 3 | 7 |
ADL5565 | 1 | 6G | 11000 | 6 | 15.5 | 80m | 2.8 | 5.2 |
AD8366 | 2 | 600M | 1.1k | 4.5 | 20.25 | 180m | 4.75 | 5.25 |
AD8475 | 1 | 150M | 50 | -8 | -2 | 3m | 3 | 10 |
ADA4930-1 | 1 | 1.4G | 2.8k |
|
| 35m | 3.3 | 5 |
ADA4930-2 | 2 | 1.4G | 2.8k |
|
| 70m | 3.3 | 5 |
LTC6409 | 1 | 2G | 3.3k | 0 |
| 52m | 2.7 | 5.25 |
AD8351S | 1 |
|
| 0 | 26 |
| 3 | 5.5 |
ADA4960-1 | 1 | 5G | 8.7k | 0 | 18 | 60m | 4.75 | 5.25 |
ADA4950-1 | 1 | 750M | 2.9k | 0 | 9.54 | 9.5m | 3 | 11 |
ADA4950-2 | 2 | 750M | 2.9k | 0 | 9.54 | 19m | 3 | 11 |
ADL5561 | 1 | 2.9G | 9.8k | 6 | 15.5 | 40m | 3 | 3.6 |
ADL5562 | 1 | 3.3G | 9.8k | 6 | 15.5 | 80m | 3 | 3.6 |
LTC6412 | 1 | 800M |
| -14 | 17 | 110m | 3 | 3.6 |
ADA4927-1 | 1 | 2.3G | 5k |
|
| 22.1m | 4.5 | 11 |
ADA4927-2 | 2 | 2.3G | 5k |
|
| 44.2m | 4.5 | 11 |
ADA4932-1 | 1 | 560M | 2.8k |
|
| 9.6m | 3 | 11 |
ADA4932-2 | 2 | 560M | 2.8k |
|
| 19.2m | 3 | 11 |
LTC6416 | 1 | 2G | 3.4k | 0 | 0 | 42m | 2.7 | 3.9 |
ADA4939-1 | 1 | 1.4G | 6.8k |
|
| 37.7m | 3 | 5.25 |
ADA4939-2 | 2 | 1.4G | 6.8k |
|
| 75.4m | 3 | 5.25 |
LT6604-10 | 2 | 10M |
| 0 |
| 35m | 3 | 11 |
LT6604-15 | 2 | 15M |
| 0 |
| 35m | 3 | 11 |
LT6604-2.5 | 2 | 2.5M |
| 0 |
| 26m | 3 | 11 |
LT6604-5 | 2 | 5M |
| 0 |
| 26m | 3 | 11 |
LTC6400-14 | 1 | 2.4G | 6k | 14 | 14 | 85m | 2.85 | 3.5 |
LTC6400-20 | 1 | 1.8G | 4.5k | 20 | 20 | 90m | 2.85 | 3.5 |
LTC6400-8 | 1 | 2.2G | 3.81k | 8 | 8 | 85m | 2.85 | 3.5 |
LTC6405 | 1 | 800M | 690 | 0 |
| 18m | 4.5 | 5.25 |
LTC6421-20 | 2 | 1.3G | 4.5k | 20 | 20 | 40m | 2.85 | 3.5 |
LTC6420-20 | 2 | 1.8G | 4.5k | 20 | 20 | 80m | 2.85 | 3.5 |
AD8372 | 2 | 130M |
| -9 | 32 | 212m | 4.5 | 5.5 |
ADA4937-2 | 2 | 1.9G | 6k |
|
| 80m | 3 | 5.25 |
ADA4938-1 | 1 | 1G | 4.7k |
|
| 40m | 4.5 | 11 |
ADA4938-2 | 2 | 1G | 4.7k |
|
| 80m | 4.5 | 11 |
LTC6401-8 | 1 | 2.2G | 3.4k | 8 | 8 | 45m | 2.85 | 3.5 |
LTC6403-1 | 1 | 200M | 200 | 0 |
| 10.8m | 2.7 | 5.25 |
AD8375 | 1 | 630M | 5k | -4 | 20 | 125m | 4.5 | 5.5 |
AD8376 | 2 | 700M | 5k | -4 | 20 | 250m | 4.5 | 5.5 |
LTC6400-26 | 1 | 1.9G | 6.67k | 26 | 26 | 85m | 2.85 | 3.5 |
LTC6401-26 | 1 | 1.6G | 3.3k | 26 | 26 | 45m | 2.85 | 3.5 |
LTC6404-1 | 1 | 600M | 450 | 0 |
| 27.2m | 2.7 | 5.5 |
LTC6404-2 | 1 | 600M | 700 | 6 |
| 29.7m | 2.7 | 5.5 |
LTC6404-4 | 1 | 530M | 1.2k | 12 |
| 30m | 2.7 | 5.5 |
LTC6410-6 | 1 | 1.4G | 1.5k | 6 | 6 | 104m | 2.8 | 5.5 |
ADA4937-1 | 1 | 1.9G | 6k |
|
| 39.5m | 3 | 5.25 |
LTC6401-20 | 1 | 1.3G | 4.5k | 20 | 20 | 50m | 2.85 | 3.5 |
LTC6406 | 1 | 800M | 630 | 0 |
| 18m | 2.7 | 3.5 |
LTC6401-14 | 1 | 2G | 3.6k | 14 | 14 | 45m | 2.85 | 3.5 |
AD8368 | 1 | 800M |
| -12 | 22 | 60m | 4.75 | 5.5 |
LT6402-12 | 1 | 300M | 400 | 12 | 12 | 30m | 4 | 5.5 |
LT6402-6 | 1 | 300M | 400 | 6 | 6 | 30m | 4 | 5.5 |
LT6411 | 2 | 650M | 3.3k | 0 | 6 | 16m | 4.5 | 12.6 |
AD8352 | 1 | 2.2G | 9k | 3 | 25 | 37m | 3 | 5.5 |
LT6600-15 | 1 | 15M |
| 0 |
| 46m | 2.7 | 11 |
LT1993-10 | 1 | 700M | 1.1k | 20 | 20 | 100m | 4 | 5.5 |
LT1993-2 | 1 | 800M | 1.1k | 6 | 6 | 100m | 4 | 5.5 |
LT1993-4 | 1 | 900M | 1.1k | 12 | 4 | 100m | 4 | 5.5 |
LT1994 | 1 | 70M | 65 | 0 |
| 13.3m | 2.375 | 12.6 |
LT6402-20 | 1 | 300M | 400 | 20 | 20 | 30m | 4 | 5.5 |
LT5524 | 1 | 540M |
| 4.5 | 27 | 34m | 4.75 | 5.25 |
LT6600-5 | 1 | 5M |
| 0 |
| 28m | 2.7 | 11 |
AD8137 | 1 | 76M | 450 |
|
| 3.2m | 2.7 | 12 |
AD8139 | 1 | 410M | 800 |
|
| 24.5m | 4.5 | 12 |
LT5514 | 1 | 850M |
| 10.5 | 33 | 64m | 4.75 | 5.25 |
AD8370 | 1 | 750M | 5.75k | -11 | 34 | 79m | 3 | 5.5 |
AD8351 | 1 | 2.2G | 13k | 0 | 26 | 28m | 3 | 5.5 |
LT6600-2.5 | 1 | 2.5M |
| 0 |
| 26m | 2.7 | 11 |
AD8369 | 1 | 600M | 1.2k | -10 | 40 | 37m | 3 | 5.5 |
LT6600-10 | 1 | 10M |
| 0 |
| 39m | 2.7 | 11 |
LT6600-20 | 1 | 20M |
| 0 |
| 46m | 2.7 | 11 |
LTC1992 | 1 | 3.2M | 1.5 | 0 |
| 650μ | 2.7 | 12 |
LTC1992-1 | 1 | 3M | 1.5 | 0 | 0 | 650μ | 2.7 | 12 |
LTC1992-10 | 1 | 4M | 2 | 20 | 20 | 650μ | 2.7 | 12 |
LTC1992-2 | 1 | 4M | 2 | 6 | 6 | 650μ | 2.7 | 12 |
LTC1992-5 | 1 | 4M | 2 | 14 | 14 | 650μ | 2.7 | 12 |
AD8132 | 1 | 350M | 1.2k |
|
| 12m | 2.7 | 11 |
AD8131 | 1 | 400M | 2k | 6 | 6 | 11.5m | 2.8 | 11 |
AD8138 | 1 | 320M | 1.15k |
|
| 20m | 3 | 11 |
AD8138S | 1 | 320M | 1.15k |
|
| 20m | 3 | 11 |
AD8350 | 1 | 900M | 2k | 20 | 20 | 30m | 5 | 10 |
